Model 10 Model 11 Model 12
▓ Network
LAN Port YES
LAN Speed 10/100 Based-T Ethernet
Supported Protocols
DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP, RTSP, RTCP,IPv4, Bonjour, UPnP,
DNS,UDP,IGMP, QoS
Number of Online Users 10
ONVIF Compatible YES (Profile S)
Security
(1) Multiple user access levels with password
(2) IP address filtering
(3) Digest authentication
Remote Access
(1) Internet Explorer on Windows operating system
(2) 16CH Video Viewer on Windows & MAC operating system
(3) EagleEyes on iPhone, iPad & Android mobile devices
▓ Video
Video Compression H.264 / MPEG4 / MJPEG
Resolution
1920 x 1080 / 1280 x 720 / 720 x 480 /
352 x 240
1920 x 1080 / 1280 x 720 / 640 x 480 /
320 x 240
1280 x 1024 / 1280 x 720 / 640 x 480 /
320 x 240
Frame Rate 30fps
Multiple Video Streaming 4 (H.264, MJPEG, MPEG4)
▓ General
Image Sensor 1/2.9" CMOS image sensor 1/ 3" SONY CMOS image sensor
Min Illumination 1 Lux / F1.4, 0 Lux (IR LED ON) 0.1 Lux / F1.5, 0 Lux (IR LED ON) 1 Lux / F1.5, 0 Lux (IR LED ON)
S/N Ratio More than 48dB (AGC off)
Electronic Shutter 1/2 to 1/10,000 sec
Lens f2.8 ~ 12mm / F1.4 ~ F2.8 f3.8mm / F1.5
Viewing Angle
Wide: 109° (Horizontal) / 76° (Vertical) /
116° (Diagonal)
Tele: 24° (Horizontal) / 13.5° (Vertical) /
27°(Diagonal)
73.2° (Horizontal) / 42.8° (Vertical) /
83.2° (Diagonal)
65.4° (Horizontal) / 49.9° (Vertical) /
80.4° (Diagonal)
IR LED 2 Units
IR Effective Range**
Default : up to 25 meters
IR Enhanced Mode : up to 35 meters
IR Shift YES
Smart Light Control NO
IRIS Mode AES
White Balance ATW
AGC Auto
WDR NO
POE (Power-over-Ethernet) Without heater YES (IEEE 802.3af)
With heater YES (IEEE 802.3at)
External Alarm I/O YES (1 input / 1 output)
MicroSD Card Slot YES (up to 64GB)
Heater Optional
IP Rating IP66
Operating Temperature Without heater -25℃ ~ 50℃
With heater -40℃ ~ 50℃
Power Source (±10%) Without heater 12V / 1A
With heater 12V / 2A
Power Consumption (±10%) Without heater PoE & PoN: 12.5W; DC Adapter: 10.25W PoE & PoN: 10W; DC Adapter: 8.5W PoE & PoN: 9.74W; DC Adapter: 8.28W
With heater PoE & PoN: 25W; DC Adapter: 21.1W PoE & PoN: 20.73W; DC Adapter: 17.62W PoE & PoN: 20.5W; DC Adapter: 17.42W
▓ Others
Mobile Surveillance iOS & Android
Push Video NO
Event Notification FTP / Email / SMS
Digital Pan / Tilt / Zoom YES
Motion Detection YES
RTC (real-time clock) YES
Minimum Web Browsing Requirements
‧Intel core i3 or higher, or equivalent AMD
‧2GB RAM
‧AGP graphics card, Direct Draw, 32MB RAM
‧Windows 7, Vista & XP, DirectX 9.0 or later
‧Internet Explorer 7.x or later
*The specifications are subject to change without notice **Using IR enhanced mode and slow shutter speed, the distance can be extended even longer.
