2x M6
4x M6
1 Nm (6x)
0,5 Nm
Cutout for escape release
Tightening torque 6 Nm
Recommended xing material:
For mounting on the mounting plate:
DIN912-M6X25-8.8ZNCYLINDER HEAD SCREW
Figure 8: Installation example for door hinged on the right (general view)
