Page #18 background imageLoading...
Page #18 background image
Operating Instructions Safety Systems
MGB-L1…-AR.-… / MGB-L2…-AR.-… and MGB-L1…-AP.-… / MGB-L2…-AP.-…
18
(Translation of the original operating instructions) 2119167-06-10/20
9. Mounting
WARNING
Mounting must be performed only by authorized personnel.
With two-leaf hinged doors, one of the two door leaves must also be latched mechanically.
Use a rod latch (Item) or a double-door lock (Bosch Rexroth) for this purpose, for example.
Important!
Ì If installed ush, the switching distance changes as a function of the installation depth and the
guard material.
Locking
module
Handle module
Locking
module
Handle module
Surface mounting
Flush installation
Actuating range
Actuating range
Tip!
Ì You will nd an animation on the mounting process at www.euchner.com.
Ì The color and labeling of pushbuttons and indicators can be modied.
For mounting steps, see Figure 8 and Figure 9 to Figure 14.
Attach system such that operation of the auxiliary release as well as inspection and maintenance are possible.
The locking screw of the auxiliary release must be returned to its original position and sealed before putting into operation
(for example with sealing lacquer).
