3. Check if your door has holes as illustrated below. If not, use the template and drill holes in your door.
Backset
2⅜ in (60 mm) or
2¾ in (70 mm)
Door Hole
Diameter
1 in (25.4mm)
Cross Bore
Diameter
2 ⅛ in (54 mm)
Door Thickness
1⅜ in - 2
¹¹
⁄
64
(35mm - 55mm)
Step 2. Install Latch & Strike Plate
1. Check your door to see if the latch requires adjustment.
If the backset is 2 ⅜ in (60 mm), use the provided latch to install.
2 ⅜ in (60 mm)
2 ⅜ in (60 mm)
