3.
Ensure the depth of the latch hole in the door frame is at least 1 in (25.4 mm), otherwise calibration may fail during setup,
and the lock may not function as expected.
Latch Hole
Depth
1 in (25.4mm)
· If the latch hole is too deep, you may install the provided plastic separator.
·The anti-picking mechanism works ONLY when the provided strike plate is installed.
Step 3. Install Exterior Assembly
1. Rotate the exterior assembly handle to the left or right. Then lock the screw into the corresponding screw hole.
Left Hand
：
G
Outside
To Next Page
