1.Refrigerator opening and closing：
Introduction Of Operating
Temperature control range: -4℉-68℉
Temperature display range: -22℉-104℉
Standard voltage input range: DC12V / 24V, maximum not exceeding DC30v
Connect the recommended DC 12 / 24 V power supply. Press the on / off button for 2 seconds to
complete the start-up. After the start-up, the display screen will normally display the current
temperature in the container, working mode and other characters. After the start-up delay (1
minute pre-set from the factory), the refrigerator goes into working mode, and the compressor
starts to work for refrigeration. To turn off the refrigerator, press the on / off button for 3
seconds while the control panel is unlocked.
2.Refrigerator control panel locking and unlocking：
If the control panel is locked (the child lock icon in the lower right corner of the display will be on),
press and hold the "up / down" button for 2 seconds at the same time to release the lock. If there
is no operation for 20 seconds, it will automatically enter the control panel lock state.
3.Set the refrigerator temperature:
When the control panel is unlocked, press the "up / down" key to adjust the temperature rise or fall
of the refrigerator (a group of temperature values on the display screen flicker to display the
current setting value). Each time you press the button, the temperature increases or decreases by 1
degree.Hold down the "Set button" button for 2 seconds, the temperature icon will flash, then use
the"UP/DOWN button" button to switch between ℃ and °F.
4.Set the compressor working mode:
When the control panel is unlocked, press the "set" button to freely switch the compressor
working mode "Eco/Max". If you need to quickly cool down to a lower temperature, you can use
the "MAX" mode. If you only need to use the refrigeration or heat preservation function, you can
set it to the "ECO" mode to save energy and power.
