Euphonix FC726 Format Converter Users Manual Introduction and Interface
12
1.2 Front Panel
The FC726’s front panel is shown in Figure 1-1. Enlarged sections of the front panel
are shown in Figure 1-2 and Figure 1-3; the numbers in the figures correspond to the
numbered items below describing that feature.
Figure 1-1 FC726 front panel
Figure 1-2 FC726 front panel (left)
44 4 4 4
1
2
333333
