Euphonix FC726 Format Converter Users Manual Pinout and Cable Specifications
38
Table A-5 FC726 ProDigi cable wiring specification continued
Connector Pin Connection Description
J2 1 J3-9
In 9+
J2 2 J3-26 In 9-
J2 3 J3-11 In 11+
J2 4 J3-28
In 11-
J2 5 J3-13
In 13+
J2 6 J3-30
In 13-
J2 7 J3-15 In 15+
J2 8 J3-32 In 15-
J2 9 J4-17 GND
J2 10 J3-10 In 10+
J2 11 J3-27 In 10-
J2 12 J3-12 In 12+
J2 13 J3-29 In 12-
J2 14 J3-14 In 14+
J2 15 J3-31
In 14-
J2 16 J3-16
In 16+
J2 17 J3-33
In 16-
J2 18 J2-23 Cable ID
J2 19 NC Cable ID
J2 20 NC Cable ID
J2 21 NC
J2 22 NC
J2 23 J2-18
GND
J2 24 NC
J2 25 NC
J2 26 J4-9
Out 9+
J2 27 J4-26 Out 9-
J2 28 J4-11 Out 11+
J2 29 J4-28 Out 11-
J2 30 J4-13 Out 13+
J2 31 J4-30 Out 13-
J2 32 J4-15
Out 15+
J2 33 J4-32
Out 15-
J2 34 J4-10 Out 10+
J2 35 J4-27 Out 10-
J2 36 J4-12 Out 12+
J2 37 J4-29 Out 12-
J2 38 J4-14 Out 14+
J2 39 J4-31 Out 14-
J2 40 J4-16 Out 16+
J2 41 J4-33
Out 16-
J2 42 NC
J2 43 NC
J2 44 NC
J2 45 NC
J2 46 NC
J2 47 NC
J2 48 NC
J2 49 NC
J2 50 J4-50
