Euphonix FC726 Format Converter Users Manual Pinout and Cable Specifications
31
Table A-3 FC726 TDIF cable wiring specification
Connecto
r
Pin Connection Description
J1 1 NC
J1 2 J2-1 In 1/2
J1 3 NC
J1 4 J2-2 In 3/4
J1 5 NC
J1 6 J2-3 In 5/6
J1 7 NC
J1 8 J2-4 In 7/8
J1 9 J2-7,24,25 GND
J1 10 NC
J1 11 NC
J1 12 NC
J1 13 NC
J1 14 NC
J1 15 NC
J1 16 NC
J1 17 NC
J1 18 J1-23 Cable ID
J1 19 NC Cable ID
J1 20 J1-23 Cable ID
J1 21 NC
J1 22 NC
J1 23 J2-17,J1-18,J1-20 GND
J1 24 J2-5 Word Clock In
J1 25 NC
J1 26 NC
J1 27 J2-13 Out 1/2
J1 28 NC
J1 29 J2-12 Out 3/4
J1 30 NC
J1 31 J2-11 Out 5/6
J1 32 NC
J1 33 J2-10 Out 7/8
J1 34 J2-8 FS0 Out
J1 35 NC
J1 36 J2-20 FS1 Out
J1 37 NC
J1 38 J2-21 Emph Out
J1 39 NC
J1 40 NC
J1 41 NC
J1 42 NC
J1 43 NC
J1 44 J2-22,23 GND
J1 45 J2-9 Word Clock Out
J1 46 NC
J1 47 NC
J1 48 NC
J1 49 NC
J1 50 J2-14,15,16 GND
Notes:
J1 = DB-50 male
J2 = DB-25 male
Twisted pairs:
J2-1/14
J2-2/15
J2-3/16
J2-4/17
J2-5/7
J2-9/22
J2-11/23
J2-12/24
J2-13/25
The rest don't matter
In and Out are from the FC727's perspective.
