Eureka 2628819 - Tent with Fly Set up

Section B
Tent with Fly Set Up: Tent, Poles, Stakes, Fly and Fly Rod
1. Assemble and stake down the tent as instructed in Section A.
2. Assemble the shock-corded y rod. Try to prevent pole sections from
snapping together, as this can damage the pole ends. Make certain each
insert (male end) has seated rmly into each plain end (female).
3. Slide the y rod through both rod sleeves and the black web loop on
the top of the camo side of the y. Insert the rod end into the grommet
on the web on one end of the y. See g 1B and 2B.
4. At the other end of the y, grasp the web loop and arch the y rod. Seat
the rod post into a grommet on the web. See g 3B.
fig 2B
fig 1B
fig 3B
