Eureka V18C01A - Repair of Main Parts; Upper, Lower Body, Motor Cover, Re-winder, Hose Assembly

4 Repair of Main Parts
4.1 Upper、Lower Body、Motor cover、Re-winder、
Hose
Assembly
1.
2.
4.
3.
5.
Remove the 6 screws from the body.
Then take the middle cover away.
Remove the four screws one by one from
the motor cover and PCB. Then take the
re-winder and air inlet cover away.
Press the button of hose connector to
release hose from main body.
