4.2 Motor
Removing
DS
4.3 connection hose ,Hose
Removing :
Remove the two screws from the motor
cover. Then take the motor cover away.
Pull the entire plug out smoothly and
press the rewinder frame to take all the
cord in to test whether it works well.
Step 1 Detach the body partition and cord reel ass.
Step 2 Remove the motor
Step 3 Take out the motor sealing, motor, motor
sponge, motor support and motor support rubber.
To Next Page
