INSTALLATION
WARNING! Risk of injury caused by falling objects
Devices in overhead installations may cause severe injuries when crashing down. Make sure that the
device is installed securely and cannot fall down. The installation must be carried out by a specialist
who is familiar with the hazards and the relevant regulations.
The device may be placed on the floor by unfolding the brackets or fastened to a truss or similar rigging structure
via one bracket. The device must never be fixed swinging freely in the room.
1 The rigging structure must support at least 10 times the weight of all fixtures to be installed on it.
2 Block access below the work area and work from a stable platform when installing the device.
3 Use rigging hardware that is compatible with the structure and capable of bearing the weight of the device.
Please refer to the “Accessories” section for a list of suitable rigging hardware.
4 Secure the device with a safety bond or other secondary attachment. This secondary safety attachment must
be sufficiently dimensioned in accordance with the latest industrial safety regulations and constructed in a way
that no part of the installation can fall down if the main attachment fails. Use the hole in the second bracket for
fixation of the safety bond. Fasten the safety bond in such a way that, in the event of a fall, the maximum drop
distance of the device will not exceed 20 cm
5 To align the device, release the fixation screws at the mounting bracket, adjust the desired inclination angle
and tighten the fixation screws.
6 After installation, the device requires inspections periodically to prevent the possibility of corrosion,
deformation and looseness.
