TIG Welding
Caution! Before starting up for the first time, read the sections
headed “Safety rules” and “Starting to use the power source”.
- Unplug the machine from the mains
- Shift the mains switch
into the "O" position
- Dismount the MIG/MAG welding torch
- Plug the earth cable into the current socket
and latch it in
firmly.
- Connect the other end of the earth cable to the workpiece
- Plug the welding cable of the TIG gas-valve welding torch
into the current socket and latch it by turning it clockwise
- Screw the pressure regulator onto the argon shielding-gas
cylinder and tighten it
- Attach the gas hose to the pressure regulator
- Plug the machine back into the mains
- Shift the mains switch into the "I" position (all the indica-
tors on the control panel briefly light up)
Caution! As soon as the process “TIG welding” is
selected, the tungsten electrode of the TIG welding torch
is live. Make sure that the tungsten electrode is not
touching any electrically conductive or earthed parts
such as e.g. the workpiece or housing.
- Use the Process button to select the process “TIG
welding” - the welding voltage to the welding socket is
switched on after a 3 sec. time-lag.
- Set the desired amperage, using the adjusting dial
- Open the gas cut-off valve on the TIG gas-valve torch and
set the desired shielding-gas flow rate on the pressure
regulator
- Start welding
N.B! Ignition of the welding arc is effected by touching
down the tungsten electrode onto the workpiece. To
finish the welding operation, simply lift the TIG gas-valve
torch away from the workpiece until the arc goes out.
Manual electrode welding
Caution! Before starting up for the first time, read the
sections headed “Safety rules” and “Starting to use the
power source”.
- Unplug the machine from the mains
- Shift the mains switch into the "O" position
- Dismount the MIG/MAG welding torch
- Depending on the type of electrode, plug the welding cable
into the current socket and turn it clockwise to latch it
- Plug the machine back into the mains
Caution! As soon as the mains switch is switched to
the "I" position, the rod electrode is live. Make sure that
the rod electrode is not touching any electrically conduc-
tive or earthed parts such as e.g. the workpiece or
housing.
- Shift the mains switch into the"I" position (all the indicators
on the control panel briefly light up)
- Using the Process button , select the manual-electrode
process - the welding voltage to the welding socket is
switched on after a 3 sec. time-lag.
- Press the adjusting dial , set the desired arc-force
- Press the Parameter Selection button until indicator
light up
- Press the adjusting dial , set the desired amperage
In order to achieve an optimum welding result, it is necessary
in some cases to make corrections to the background parame-
ters Hot-Current time and / or Hot-Start current.
