Eutectic+Castolin TotalARC 2 3000 - Technical Data

52
Warning! If the machine is designed to run on a special
voltage, the Technical Data shown on the rating plate
apply. The mains plug and mains supply lead, and their
fuse protection, must be dimensioned accordingly.
Technical Data
TOTAL ARC² 3000 / 4000 / 5000 power source
TOTAL ARC
2
3000 TOTAL ARC
2
4000 TOTAL ARC
2
5000
Mains voltage 3x400 V 3x400 V 3x400 V
Mains fuse protection (slow-blow) 16 A 35 A 35 A
Primary continuous power (100% duty cycle) 4,5 kVA 12,7 kVA 15,1 kVA
Cos phi 0,99 0,99 0,99
Efficiency 87 % 88 % 89 %
Welding current range MIG/MAG 3 - 270 A 3 - 400 A 3 - 500 A
Electrode 10 - 270 A 10 - 400 A 10 - 500 A
TIG 3 - 270 A 3 - 400 A 3 - 500 A
Welding current at 10 min/25°C 60% d.c. 270 A 400 A -
10 min/25°C 75% d.c. - - 500 A
10 min/25°C 100% d.c. 210 A 365 A 450 A
10 min/40°C 40% d.c. 270 A - 500 A
10 min/40°C 50% d.c. - 400 A -
10 min/40°C 60% d.c. 210 A 365 A 450 A
10 min/40°C 100% d.c. 170 A 320 A 360 A
Open-circuit voltage 50 V 70 V 70 V
Working voltage MIG/MAG 14,2 - 27,5 V 14,2 - 34,0 V 14,2 - 39,0 V
Electrode 20,4 - 30,8 V 20,4 - 36,0 V 20,4 - 40,0 V
TIG 10,1 - 20,8 V 10,1 - 26 V 10,1 - 30 V
Degree of protection IP 23 IP 23 IP 23
Type of cooling AF AF AF
Insulation class B F F
Dimensions L x W x H mm 940/580/900 910/580/900 910/580/900
Weight 71 kg 75 kg 75 kg
S, CE S, CE S, CE
DS III wire feeder
Supply voltage 55 V DC
Rated current 4 A
Wire diameter 0,8 - 1,6 mm
Wire speed 0,5 - 22 m/min
Degree of protection IP 23
Dimensions L x W x H mm 660/270/420
Weight 17,3 kg
Cooling unit (built in power source)
Mains voltage 400 V, 50 Hz
Power consumption 0,5 A / 0,6 A
Colling capacity at Q=1l/min, +20°C 1600 W
Cooling capacity at Q=max, +20°C 1800 W
Max. delivery capacity 3,5 l/min.
Max. pump pressure 4,2 bar
Pump Centrifugal pump
Coolant volume 5,5 l
Degree of protection IP 23
