Eutectic+Castolin TotalARC 2 3000 - Retrieving and Deleting Stored Jobs

46
Deleting a Job
A job that has been stored to a program location can also be
deleted again. To delete a job, proceed as described below:
- Briefly press down MEM button to change to the job menu.
The first vacant program location for the Job is indicated.
- With the Program button
, select the job to be deleted
(Indicator CLEAR lights up)
- Press up and hold the MEM button . The left-hand display
reads “dEL” - the job is deleted.
- Briefly press down the MEM button
to exit from the job
menu
“nPG" appears on the left-hand display to indicate that the
job is now deleted. Release the MEM button
.
Retrieving a Job
Once programmed, all jobs can be retrieved in Job Mode. To
retrieve a job, proceed as follows:
- With the Process button , select MIG/MAG welding
- With the MIG/MAG mode button , select the MIG/MAG job
mode (MEM) - the last job will be displayed
- Using the Program button
to select the desired job
N.B.! When you retrieve a job directly from the power source,
you can also select vacant program locations (symbolised by
“- - -”)
- Start welding - during welding you can always change to
another job without interruption.
- When you change to another program, this finishes Job
Mode.
- Briefly press down the MEM button
to exit from the job
menu
P R G
3
5 . 5
2 4 . 6
2 6
N P G
3
D E L
3
P R G
3
N P G
0
5 . 5
2 4 . 6
2 6
3 . 8
2 0 . 7
2
5 . 5
2 4 . 6
1
5 . 5
2 4 . 6
2 6
P R O
1
To view the settings programmed in this job, use the
Parameter Selection buttons and . The MIG/MAG
operating mode and the welding torch operating mode of the
stored job are displayed.
By pressing the MEM button and the MIG/MAG mode
button at the same time the corresponding program
("characteristic") will be displayed from which the job was
created at first. Press the MEM button to exit.
