PMC-E FORCED DRAFT EVAPORATIVE CONDENSERS
Table 6 – Minimum “H” Dimension for Rigging Discharge Hoods and Discharge Attenuation
Rigging Hardware Parts List
The following table lists those parts which are shipped together with the unit(s) for field assembly.
Box Size (m) “H” Dimensions (mm)
1.5m Wide Models
1.5 x 3.6 3073
1.5 x 5.4 4674
3m Wide Models
3 x 3.6 3073
3 x 5.4 4674
3 x 7.2 3073
3 x 11 4674
3.6m Wide Models
3.6 x 3.6 3073
3.6 x 5.4 4674
3.6 x 6 5207
3.6 x 7.2 3073
3.6 x 12.2 5207
(See Table 2 for model numbers corresponding to box size)
Box Size (m) Bolt
1
Lock Nut
1
Washer
1
Sealer Tape
1.5 x 3.6 14 14 28 3
1.5 x 5.4 16 16 28 3
3 x 3.6 14 14 28 4
3 x 5.4 16 16 32 5
3 x 7.2 28 28 56 8
3 x 11 32 32 64 10
3.6 x 3.6 14 14 28 5
3.6 x 5.4 16 16 32 6
3.6 x 6 16 16 32 6
3.6 x 7.2 28 28 56 10
3.6 x 11 32 32 64 12
3.6 x 12.2 32 32 64 12
Table 7 – Parts Shipped with Unit(s) by Box Size
(See Table 2 for model numbers corresponding to box size)
1
5/16”Diameter Hardware
