Evco c-pro 3 nano Series User Manual

EVCO S.p.A. c-pro 3 nano | Hardware Manual ver. 1.0 | Code 114CP3NE104
page 18 of 26
36
PAr
Parameters
-
only available
for c-pro 3 nano
plus
AO 3
AO 3
010V
0-10V
type of signal analogue output 3
0-20 = 0-20 mA
0-20mA
4-20 = 4-20 mA
4-20mA
0-10 = 0-10 V
0-10V
37
PAr
Parameters
-
only available
for c-pro 3 nano
plus
AO 4
AO 4
010V
0-10V
type of signal analogue output 4
0-20 = 0-20 mA
0-20mA
4-20 = 4-20 mA
4-20mA
0-10 = 0-10 V
0-10V
38
Par > Par2
Parameters
IOto
I/O Timeout
60
60
remote I/O disable delay by lack of CAN
communication
1... 240 s
39
Par > Par2
Parameters
EnLE
En. Prg Level
nO
NO
enable access to the first level page by touching a
key
yES YES = proceed as follows.
- touch the SET key for 3 seconds to
access the first page of level 1
- touch the SET key for 3 seconds to
access the first page of level 2
- touch the SET key for 3 seconds to
access the first page of level 3
40
Par > Par2
Parameters
PUIn
Password Indi
nO
NO
password requirement for access to the different
levels
nO NO = access to a lower level does not require
a password
yES YES = access to each level requires a
password
41
nEt > CAn
Networks > CAN
Bus
-
not available for
c-pro 3 nano
basic
nLoG
MyNode
1 device CAN address 1... 127
42
nEt > CAn
Networks > CAN
Bus
-
not available for
c-pro 3 nano
basic
MASt
Master
YES
YES
enable master function in a CAN network YES YES = YES
43
nEt > CAn
Networks > CAN
Bus
-
not available for
c-pro 3 nano
basic
bAUd
Baud
20
20K
baud rate in a CAN network
20 = 20,000 baud
20K
50 = 50,000 baud
50K
125 = 125,000 baud
125K
500 = 500,000 baud
500K
44
nEt > CAn
Networks > CAN
Bus
-
not available for
c-pro 3 nano
basic
tiME
Time
5
exclusion of a CAN network device delayed by lack of
communication
1... 60 s
