EVCO S.p.A. c-pro 3 NODE kilo+ | Hardware manual ver. 1.0 | Code 114CP3NKPE104
AI2 - - - - - - - - - NTC
type of probe analog port 2
PTC = PTC probe
NTC = NTC probe
0-20mA = Transducer 0-20 mA
4-20mA = Transducer 4-20 mA
0-5V = Transducer 0-5 V ratiometric
0-10V = Transducer 0-10 V
PT1000 = Pt 1000 probe
NTCK2 = Type 2 NTC probe
NTCK3 = Type 3 NTC probe
RESIST = electric resistance reading
AI3 - - - - - - - - - NTC
type of probe analog port 3
PTC = PTC probe
NTC = NTC probe
0-20mA = Transducer 0-20 mA
4-20mA = Transducer 4-20 mA
0-5V = Transducer 0-5 V ratiometric
0-10V = Transducer 0-10 V
PT1000 = Pt 1000 probe
NTCK2 = Type 2 NTC probe
NTCK3 = Type 3 NTC probe
RESIST = electric resistance reading
AI4 - - - - - - - - - NTC
type of probe analog port 4
PTC = PTC probe
NTC = NTC probe
PT1000 = Pt 1000 probe
NTCK2 = Type 2 NTC probe
NTCK3 = Type 3 NTC probe
RESIST = electric resistance reading
AI5 - - - - - - - - - NTC
type of probe analog port 5
PTC = PTC probe
NTC = NTC probe
PT1000 = Pt 1000 probe
NTCK2 = Type 2 NTC probe
NTCK3 = Type 3 NTC probe
RESIST = electric resistance reading
AI6 - - - - - - - - - NTC
type of probe analog port 6
PTC = PTC probe
NTC = NTC probe
PT1000 = Pt 1000 probe
NTCK2 = Type 2 NTC probe
NTCK3 = Type 3 NTC probe
RESIST = electric resistance reading
page 34 of 55
