EVCO S.p.A. c-pro 3 NODE kilo+ | Hardware manual ver. 1.0 | Code 114CP3NKPE104
AI7 - - - - - - - - - NTC
type of probe analog port 7
PTC = PTC probe
NTC = NTC probe
0-20mA = Transducer 0-20 mA
4-20mA = Transducer 4-20 mA
0-5V = Transducer 0-5 V ratiometric
0-10V = Transducer 0-10 V
PT1000 = Pt 1000 probe
NTCK2 = Type 2 NTC probe
NTCK3 = Type 3 NTC probe
RESIST = electric resistance reading
AI8 - - - - - - - - - NTC
type of probe analog port 8
PTC = PTC probe
NTC = NTC probe
0-20mA = Transducer 0-20 mA
4-20mA = Transducer 4-20 mA
0-5V = Transducer 0-5 V ratiometric
0-10V = Transducer 0-10 V
PT1000 = Pt 1000 probe
NTCK2 = Type 2 NTC probe
NTCK3 = Type 3 NTC probe
RESIST = electric resistance reading
AI9 - - - - - - - - - NTC
type of probe analog port 9
PTC = PTC probe
NTC = NTC probe
0-20mA = Transducer 0-20 mA
4-20mA = Transducer 4-20 mA
0-5V = Transducer 0-5 V ratiometric
0-10V = Transducer 0-10 V
PT1000 = Pt 1000 probe
NTCK2 = Type 2 NTC probe
NTCK3 = Type 3 NTC probe
RESIST = electric resistance reading
AI10 - - - - - - - - - NTC
type of probe analog port 10
PTC = PTC probe
NTC = NTC probe
PT1000 = Pt 1000 probe
NTCK2 = Type 2 NTC probe
NTCK3 = Type 3 NTC probe
RESIST = electric resistance reading
Al Err Time 0 240 s 2
analog ports time-out (if no communication with an analog port
is detected after this span of time, the controller notifies an
analog input error)
AO impulse 1 50 ms/10 20 duration of the cut phase impulse
page 35 of 55
