Evco EVJ LCD Applications Manual

EVCO S.p.A. EV3 MVC & EVD MVC | Application manual ver. 2.2c | Code 1443DMVCI224
page 39 of 74
Label
Default
value
Default
visibility
Min Max um Description
t30 0 U 0 2 Band type for Friday
t31 1 U 0 2 Band type for Saturday
t32 2 U 0 2 Band type for Sunday
t33 16 U 0 100 Holiday end year
t34 1 U 1 12 Holiday end month
t35 1 U 1 31 Holiday end day
t36 0 U 0 23 Holiday end hour
SP Setpoint Parameters
P01 21.0 U C02 C01 °C-°F Temperature setpoint Heating mode Comfort setting
P02 25.0 U C04 C03 °C-°F Temperature setpoint Cooling mode Comfort setting
P03 -1.0 U -12.7 12.7 °C-°F Temperature offset Heating mode Economy setting
P04 1.0 U -12.7 12.7 °C-°F Temperature offset Cooling mode Economy setting
P05 -2.0 U -12.7 12.7 °C-°F Temperature offset Heating mode Night setting
P06 2.0 U -12.7 12.7 °C-°F Temperature offset Cooling mode Night setting
P07 21.0 U C02 C01 °C-°F Temperature setpoint Heating mode Manual setting
P08 25.0 U C04 C03 °C-°F Temperature setpoint Cooling mode Manual setting
P09 80 U C06 C05 % Fan speed setpoint comfort setting
P10 60 U C06 C05 % Fan speed setpoint economy setting
P11 40 U C06 C05 % Fan speed setpoint night setting
P12 80 U C06 C05 % Fan speed setpoint manual setting
P13 100 U C06 C05 % Fan speed setpoint digital input setting
P14 40 U C08 C07 % Damper opening setpoint comfort setting
P15 30 U C08 C07 % Damper opening setpoint economy setting
P16 20 U C08 C07 % Damper opening setpoint night setting
P17 40 U C08 C07 % Damper opening setpoint manual setting
CNF Configuration Parameters
C01 30.0 S P01 100.0 °C-°F Maximum Temperature Setpoint Value in Heating Mode
C02 10.0 S 0.0 P01 °C-°F Minimum Temperature Setpoint Value in Heating Mode
C03 30.0 S P02 100.0 °C-°F Maximum Temperature Setpoint Value in Cooling Mode
C04 10.0 S -10.0 P02 °C-°F Minimum Temperature Setpoint Value in Cooling Mode
C05 100 S C06 100 % Maximum Fan Setpoint Value
C06 10 S 0 C05 % Minimum Fan Setpoint Value
C07 100 S C08 100 % Maximum damper setpoint value
C08 10 S 0 C07 % Minimum damper setpoint value
C09 1 M 0 1
Enable RTC
0: OFF
1: ON
C10 0 M -32,768 32,767 Parameter unused
C11 1 S 0 2
Changeover mode
0: Manual
1: Manual + Automatic
2: Auto
C12 5 M 1 100 % Fan/damper control step
C13 10 M 1 255 s Increase/decrease fan/damper control time
C14 20 M C06 C05 % Minimum fan value with compressor ON
C15 20 M C06 C05 % Minimum fan value with 1 heater ON
C16 30 M C06 C05 % Minimum fan value with 2 heaters ON
C17 30 M 0 255 s Post-ventilation from OFF
C18 -12 S -127 127 Servicer password
C19 -123 M -127 127 Manufacturer password
