EVCO S.p.A. EV3 MVC & EVD MVC | Application manual ver. 1.0 | Code 144EV3MVI104
page 39 of 72
Label Default Min. Max. U.M. Description
I66 0 0 5 AO2 expansion analogue output function configuration; see parameter I63
I67 0 0 1
TK1 (EV3)/OC (EVD) analogue output function configuration
0 = Disabled (or DO)
1 = Heaters
I68 0 0 1
TK2 analogue output function configuration
0 = Disabled (or DO)
1 = Heaters
I69 0 0 1
OC expansion analogue output function configuration
0 = Disabled (or DO)
1 = Heaters
I71 2 0 4
AO1 analogue output type configuration
0 = Disabled (or DO)
1= Phase cutting
2 = 0-10 V
3 = PWM
4 = Frequency
I72 2 0 4 AO2 analogue output type configuration; see parameter I71
I73 100 1 200 Hz*10 PWM output frequency
I74 0 0 4 AO1 expansion analogue output type configuration; see parameter I71
I75 0 0 4 AO2 expansion analogue output type configuration; see parameter I71
I76 100 1 200 Hz*10 Expansion PWM output frequency
