EVCO S.p.A.
EV3 MVC & EVD MVC | Application manual ver. 1.0 | Code 144EV3MVI104
page 26 of 72
6 MENU
6.1 Menu list
The following menus are available:
SEt Provides access to the quick setting function of the regulation setpoints
FAN: fan speed setpoint regulation
dAM: open fan setpoint regulation
tMP: temperature setpoint regulation
tbM: operating timer settings
StA Shows machine status (see chapter 11)
AL Shows the list of alarms underway (see section 10)
PAr Shows and allows the device parameters to be altered. The parameters are grouped according to their function, identified on
the display by a label. Each parameter has an alphabetic code followed by two numbers, as shown in the table below.
Group Identification label Parameter code
Timer settings tb t
Setpoint SP P
Configuration CnF C
Defrost dEF d
Alarm ALM A
Inputs/outputs IO I
Hr Shows the operating hours
HCP: compressor operating hours
HFA: fan operating hours
HUn: unit operating hours
Press the SET key for about 3 seconds to set the operating hours to zero if at least the service level password has been entered
HiS Enables up to 20 alarm events to be saved
ViS: the historical details are shown on the lower display in the following sequence:
y xx year if the clock is available or alarm number
M xx month if the clock is available
d xx day if the clock is available
hh:mm hours:minutes if the clock is available
cLS: deletes historical details
rtc Enables the time to be set in devices with a clock
YEA: set year
Mon: set month
dAY: set date
UdA: set day of the week
Hou: set hour
Min: set minutes
inFo Enables the project data to be seen in this sequence
Project
Variation
Revision:Version
PAS Enables the password to be entered to access the desired level: parameter C18 for servicer level, C19 for manufacturer level.
