EVCO S.p.A. EV3 MVC & EVD MVC | Application manual ver. 1.0 | Code 144EV3MVI104
page 69 of 72
EV3K11 none
EVJ LCD none
Analogue outputs 0-10 V (max. 10 mA)
Minimum load impedence:1 KΩ
Resolution: 0.01 V
Protection: none
Phase cutting analogue outputs
Output: 10 VDC, max. 10 mA
Frequency: synchronised with that of the power supply
Pulse duration: 500 µs
Shift: 20... 90 %
Protection: none
PWM analogue outputs
Output: 10 VDC, max. 10 mA
Frequency: 10... 2 KHz
Duty: 5... 95 %
Protection: none
Frequency analogue outputs
Output: 10 VDC, max. 10 mA
Frequency: 10Hz ... 255 Hz
Duty: 50%
Protection: none
Digital outputs
EV3 MVC
Up to 6 outputs:
- 4 SPST relays, 3 A res. @ 250 VAC
- 1 200 mA triac res. @ 250 VAC at 25°C (77°F)
- 1 2 A triac res. @ 250 VAC at 25°C (77°F)
EVD MVC
EVD EXP
Up to 5 outputs:
- 2 SPST relays, 3 A res. @ 250 VAC
- 1 SPST relay, 8 A res. @ 250 VAC
- 1 SPST relay, 12 A res. @ 250 VAC
- 1 open collector, 12 VDC, max. 40 mA
EV3K11 none
EVJ LCD none
Type 1 or Type 2 Actions
EV3 MVC
Type 1
EVD MVC
EVD EXP
EV3K11 Not applicable
EVJ LCD Not applicable
Additional features of Type
1 or Type 2 actions
EV3 MVC
C
EVD MVC
EVD EXP
EV3K11 Not applicable
EVJ LCD Not applicable
Displays
EV3 MVC 4+4 digit LED display
EVD MVC
EVD EXP
Signalling LED
