EVCO S.p.A. EVXV 800 range | Installer manual ver. 1.2 | Code 144XV800E124
page 7 of 66
1.2 Summary table of the main features and the models
available
The following table illustrates the main features of the devices and the models available.
“/“ indicates the feature can be set via a configuration parameter.
User interface (without cover) EVXV802 EVXV812 EVXV805 EVXV815
63.8 x 110.0 mm (2.511 x 4.330 in;
L x H)
• • • •
custom 4 digit display (with function icon) • • • •
number of keys 6 6 8 8
°C decimal point • • • •
Connections EVXV802 EVXV812 EVXV805 EVXV815
faston + fixed screw terminal board • • • •
Power supply EVXV802 EVXV812 EVXV805 EVXV815
230 VAC • • • •
Analogue inputs EVXV802 EVXV812 EVXV805 EVXV815
cabinet probe PTC/NTC PTC/NTC PTC/NTC PTC/NTC
needle probe PTC/NTC PTC/NTC PTC/NTC PTC/NTC
evaporator probe PTC/NTC PTC/NTC PTC/NTC PTC/NTC
condenser probe/high pressure input PTC/NTC PTC/NTC PTC/NTC PTC/NTC
Digital inputs (for
NO/NC contact)
EVXV802 EVXV812 EVXV805 EVXV815
door micro switch • • • •
high pressure/condenser probe • • • •
Digital outputs (electromechanical
relays; A res. @ 250 VAC)
EVXV802 EVXV812 EVXV805 EVXV815
compressor 30 A 30 A 30 A 30 A
defrosting 8 A 8 A
