THERMOSTAT WIRING FOR DGAT AND DGAM SERIES
Figure17 -- Thermostat Wiring
White
Green
Black
Red
Blend Air
Control Box
Condensing
Unit
Wall Thermostat
F urnace Control Box
Not Factory Installed
White
Green
Black
Red
Yellow
White
Green
Red
Yellow
