Evcon DLAS075BDD User Manual

28
DGAM, DGAT, & DLAS SERIES
HSI GAS DOWN FLOW FURNACE
CODE
USED ON
MODEL
NO.
REQ.
PART
NUMBER
DESCRIPTION
10 ALL 1 7945--- 1351/B Cover (Control Box)
*
12 ALL 1 7990--- 319P Integrated Control
*
15 ALL 1 7990--- 326PBB Gas Valve (24V .5 Amp
1
/
2
”x
3
/
8
”)
1 6 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
17 ALL 1 7945--- 5151/C Valve Bracket
18 DGAM,DGAT 1 7956A5201 Panel (Coil Cavity 19
13
/
16
”
1 9 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
*
20 ALL 1 7670--- 368P/A Thermostat (Adj. Ant.)
21 ALL 1 7945--- 3011 Gasket Pkg. (Heat Exchanger)
22 ALL 1 7995---5751 Heat Exchanger (with Gaskets)
*
23 ALL 1 7975---3881 Remote Sensor
24 ALL 1 7681--- 3301 System Switch
25 ALL 1 7956---1121 Junction Box Cover
*
26 ALL 1 2940A3541 Transformer (115---24V 40VA)
*
29 056
070,075
090
1 7945--- 3281/A
7970--- 3281/A
7995--- 3381/A
L i m i t S w i t c h ( O P E N --- 1 4 0 ˚ C L O S E --- 1 1 0 ˚)
L i m i t S w i t c h ( O P E N --- 1 4 5 ˚ C L O S E --- 1 1 5 ˚)
L i m i t S w i t c h ( O P E N --- 1 5 0 _ C L O S E --- 1 2 0 _)
31 ALL 1 7970--- 5851/A Burner Assembly (Less Gas Valve ---
Includes Codes 32, 33, 34)
*
32 ALL 1 1474---0521 Hot Surface Ignitor
33 ALL 1 7970---179 Ignitor Shield
34 ALL 1 7945---1631/A Mounting Plate (Burner)
3 5 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
*
36 ALL 1 1214---2511 Filter (16 x 20 x 1 Disposable) (2 Required)
37 DGAM
DLAS, DGA T
1
1
1
7975--- 1561/B
7990--- 1561/A
Panel (Upper)(White)
Panel (Upper)(White)
38 DGAM,DGAT
DLAS
1
1
7956--- 1571/A
7956--- 1631/A
Panel (Lower)(White)
Panel (Lower)(White)
BLOWER PARTS
*
39 DGAM 1 1468--- 220P Motor
DGAT, DLAS
(057, 070, 075)
1 7966--- 311P Motor
090 1 1468--- 212P Motor
40 All 1 7966A530 Scroll
41 All 1 2702--- 4091 Motor Mount(3/Pkg.)
42 All 1 7680--- 348 Connector Plug
43 All 1 7670--- 6391 Motor Clamp
*
44 090
DGAM
1
1
1499--- 4461
1499--- 4471
Run Capacitor
Run Capacitor
45 All 1 1472--- 2751 Blower Wheel
(10 5/8 Dia. x 7 1/8 x 1/2)
BURNER ORIFICE CHART
MODEL 056 070 075 090
Nat. 9951---1281 9951---1491 9951---1541 9951---1771
LP 9951---0821 9951---0931 9951---0961 9951---1041
BB NOTE: The 7707---326P is a designed approved alternate for this valve.
NOTE: All parts with three digit suffix numbers are “Special Order” Parts. These parts are subject to factory availabilit y and require extra
time for delivery.
* Suggested Parts Inventory (2% of Units Installed---Minimum 1 each)
3110 North Mead
P.O. Box 19014
Wichita, KS 67204---9014
Evcon Industries, Inc.
1973---106/B Rev.5 (4/97) P.I.
