DGAM, DGAT & DLAS SERIES
HSI Gas Do wnflow Furnace
Repair Parts List for:
DGAM056BDD DG AT056BDD DLAS056BDD DGAT070BDD DGAM075BDD DG AT075BDD DLAS075BDD DGAT090BDD
29
25
20
36
37
38
22
5
21
21
40
44
3
4
6
7
8
9
2
15
45
43
42
41
39
32
33
31
34
17
18
10
23
24
12
26
BURNER
ORIFICE
(SEE CHART)
CODE
USED ON
MODEL
NO.
REQ.
PART
NUMBER
DESCRIPTION
__ ALL X 8B246P
8B247P
Enamel (Spray 15 oz. Almon d)
Enamel (Spray 15 oz. White)
2 ALL 1 7945A5721 Casing Top
*
3 ALL 1 7990--- 3591B Limit Switch (Upper)
(180˚ Manual Reset)
4 ALL 1 7990--- 6451 Booster Assembly (Includes Code 5 --- 9)
5 ALL 1 7995A386 Booster Gasket
6 ALL 1 2900--- 3601 Impellor (3
13
/
16
x1
7
/
8
x
1
/
4
)
7 ALL 1 2900--- 147 Mount Plate (Booster Motor)
8 ALL 1 7990--- 300 Motor Mount Plate Gasket
*
9 ALL 1 7990--- 317P Booster Motor --- 3000 RPM
B
NOTE: The 7624A3591 (180˚ Manual Reset) is a designed approved alternate for this limit switch.
