FURNACE SPECIFICATIONS
TABLE 1 — Furnace Specifications
DGAM — Automatic ignition — with Built-- in Coil Cabinet — 4 Ton -- A/C Ready
Model No. Factory Equipped for use with: Input/BTUH Output/BTUH
DGAM056BDD NATURAL GAS 56,000 46,000
DGAM075BDD NATURAL GAS 75,000 61,000
DGA T — Automatic Ignition — with Built--in Coil Cabinet — 3 Ton -- A/C Ready
Model No. Factory Equipped for use with: Input/BTUH Output/BTUH
DGAT056BDD NATURAL GAS 56,000 46,000
DGAT070BDD NATURAL GAS 70,000 57,000
DGAT075BDD NATURAL GAS 75,000 61,000
DGAT090BDD NATURAL GAS 90,000 72,000
DLAS — Automatic Ignition — Heating Only — No Coil Cabinet
Model No. Factory Equipped for use with: Input/BTUH Output/BTUH
DLAS056BDD PROPANE 56,000 47,000
DLAS075BDD PROPANE 75,000 62,000
TABLE 2 — Electrical Specifications
Electrical Pow er Supply — 120 Volts — 60 Hz — 1 Phase
BreakerorFuse— 15 Amp
Thermostat Circuit — 24 Volt — 60 Hz — 40 VA
Nominal Anticipator Setting — .50
Gas Valve Inlet —
1
/
2
”NFPT
