Installing the Base with the Vehicle Seat
Belt/Shoulder Belt (cont.)
CHECK the recline indicator
to make sure the base is
correctly reclined. If it is not
correctly reclined, unlock
the Fit-loc belt tightener,
unbuckle lap/shoulder belt,
and adjust the foot on the
base then re-install base.
CHECK that the base is
correctly reclined. Refer to
pages 66-70 for Adjusting the
Recline.
9
8
To remove the carrier
from the base, squeeze the
release handle at the back of
the carrier. Lift carrier away
from the base.
To remove the base from
vehicle,
squeeze the button on the
Fit-loc belt tightener and lift it
up (see Step 2 and 3 on page
58) then unbuckle the vehicle
belt and remove it from the
belt path.
11
CLICK!
Attach the carrier into the
base until you hear a click.
Finish the load leg adjustment
from pages 38-41
ALWAYS Lift up on the
handle of the carrier
to make sure that it is
securely attached in the
base.
10
Installing the Base with the Vehicle Seat
Belt/Shoulder Belt (cont.)
