80 81
Small
Approximate
Child Size:
Waist Strap
Position:
Medium
Large
Inner
Middle
Outer
1.8 - 2.7 kg
2.7 - 9 kg
9 - 15.8 kg
(4 - 6 lbs)
(6 - 20 lbs)
(20 - 35 lbs)
Inner
Inner
Middle
Middle
Outer
Outer
Changing the Waist Strap Position Changing the Waist Strap Position (cont.)
As your child grows, you will need to change the waist
strap position so that it is in the slot closest to your
child. The waist strap should ALWAYS be as close as
possible to, but NEVER under, the child’s legs.
PLACE AT ARMPIT LEVEL
SENSOR
SAFE
Push the crotch strap
through the slot in the seat
pad
To reposition waist straps,
loosen the harness straps
by pressing the harness
release button while
pulling on the harness
straps.
1
2
Unhook the front of the child restraint’s
seat pad and move it out of the way
to expose the waist strap slots and
anchors.
Remove the waist strap anchor from its
position on top of the seat, and push
the anchor down through the slot to the
bottom of the seat. Then push anchor
up through the slot to the top of the seat
pad. Repeat on other side.
3
