Adjusting the Recline
Checking the Recline with the Base
To raise the base, push the
button and the foot will
spring down into one of
the 4 positions until it locks
into place.
To lower the base, push
the button and push foot
up into base until it locks
into desired position.
The slope of the vehicle
seats vary so your child
restraint base has a feature for
adjusting the proper recline
angle.
The base has 4 recline
adjustment positions for the
foot.
When using the carrier and the base together:
1) Make sure vehicle is on
level ground.
2) Only use the recline
indicator on the base to
make sure the seat and base
are correctly reclined.
3) Recline base until you see
only green or only blue.
Blue : 4-20lbs
(1.8 -9.1 kg)
Green : 20-35lbs
(9.1 -15.9kg)
NEVER allow green and blue
to be showing in the window
at the same time. The recline
is NOT correct.
If seat is still not correctly
reclined, see Adjusting the
Recline.
