Installing the Base with the Vehicle
Seat Belt (cont.)
Installing the Base with the Vehicle
Seat Belt (cont.)
CHECK the recline indicator
to make sure the base is
correctly reclined. If it is not
correctly reclined, unlock
the Fit-loc belt tightener,
unbuckle lap belt, and adjust
the foot on the base then re-
install base.
CHECK that the base is
correctly reclined. Refer to
pages 66-70 for Adjusting the
Recline.
9
8
10
To remove the carrier from
the base, squeeze the release
handle at the back of the
carrier. Lift carrier away from
the base.
To remove the base from
vehicle,
squeeze the button on the
Fit-loc belt tightener and lift
it up (see Step 2 and 3 on
page 58) then unbuckle the
vehicle belt and remove it
from the belt path.
11
CLICK!
Attach the carrier into the
base until you hear a click.
Finish the load leg
adjustment from pages
38-41.
ALWAYS Lift up on the
handle of the carrier to
make sure that it is securely
attached in the base.
