E
D
E
D
18 19
C
Pull the seat pad off of
the front of the child
restraint.
Route the LATCH harness
and hook through the
rear-facing belt paths C.
Refer to your vehicle owner’s manual to locate the lower
anchors on your vehicle seat. Attach the right hook D to
the right anchor E, and the left hook to the left anchor.
DOUBLE CHECK that the LATCH hook is fully engaged
by pulling hard on the LATCH harness.
2
3
4
DO NOT use this child restraint if it moves more than
1 in. (25 mm) forward or side-to-side at the vehicle
belt path. Serious injury or death may result from poor
installation. If you can not tightly secure the child
restraint, try again or move it to another location.
WARNING
Using your full weight push the child restraint firmly into
the vehicle seat, while pulling up on the LATCH harness
to tighten.
The LATCH harness must be as tight as possible.
If you can move the child restraint more than 1 in.
(25 mm) forward or side-to-side at the LATCH harness
path C, the belts are not tight enough. You MUST try
again, or find another location for your child restraint.
➚
➚
C
Make sure that the harness
straps are in one of the three
lower harness positions A.
The harness straps must start
at or below shoulder height,
using the strap slots closest
to your child’s shoulders B,
as shown.
Infants MUST always ride facing the rear of the
vehicle. The back of the child restraint supports and
protects the baby and absorbs crash forces.
Adjust the child restraint to the Recline position (p. 16).
Place the child restraint in your vehicle rear-facing.
A
1
B
DO NOT use the upper harness slots rear-facing. The harness
may not properly restrain the child during a crash.
WARNING
NEVER turn a child restraint
forward-facing with an infant
weighing less than 20 lbs (9 kg)
or less than one year of age.
Crash forces may cause serious
injury or death.
WARNING
Rear-facing Use
