32 33
Toddler
Infant
D
E
F
There are two positions
on the harness straps.
The top loop E is for
infant use. The bottom
loop F is for use as
your child grows.
Reattach the harness
strap onto the splitter
plate
D
.
Repeat on the other
side.
1
➚
Pull harness strap through to the front of the child
restraint.
Thread each harness strap through the appropriate
slot in the seat shell and the pad.
Pull the harness strap to the back of the child restraint.
To change the harness strap position, loosen the
shoulder harness, as shown on page 34, step 2.
Slide the harness strap off of the splitter plate D.
We suggest you do this one side at a time.
D
1
2
3
When Using in Rear-facing Position
The shoulder harness straps MUST ALWAYS be at
or below the child’s shoulders in one of the three
lower harness positions A or B and the child’s head
MUST be at least 1 inch (25 mm) below the top of
the seat back.
When Using in Forward-facing Position
The shoulder harness straps MUST ALWAYS be at
or above the child’s shoulders in one of the three
top harness position B or C. If the top of the child’s
ears are above the top of the seat back, the child’s
shoulders fall above the highest set of harness slots, or
the child weighs more than 40 lbs (18 kg) you MUST
discontinue use of this child restraint. We recommend
that you move your child to a larger child restraint or
booster seat.
Positioning the Harness Strap
Forward-facing ONLY
Top Harness Position
C
Forward- OR Rear-facing
Middle Two Harness
Positions
B
Rear-facing ONLY
Lowest Harness Position
A
Shoulder harness straps on this child restraint are
adjustable to four positions.
General
Information
