Even-GLO™ Series GA301
Page 27
October-28-15
Hanging Model GA301H
Ceiling Mount
A.Disconnect gas hose from reducing coupling.
B. Connect Flared Elbow to reducing coupling and align elbow to
point at a right angle to heater door opening.
C. After inserting heater assembly into frame base, connect the Swivel Fitting on the
opposite end of the gas hose to the Flared Elbow.
The picture to the right shows how it should look like.
Note: All gas connections must be done according to local and national codes.
Also, all new connections must be leak tested.
