Even-GLO™ Series GA301 Page 6 October-28-15
Pre-installation Overview
Hardware Kits
MODEL GA301-MP:
EH001: Top Reflector to Support Arms (Blue Tape)
 EH027: 1/4”-20 x 1/2” S.S Carriage Bolt (x4), CH143: 1/4” S.S Flat Washer (x4),
EH028 1/4”-20 S.S Acorn Nut (x4)
EH084: Housing Top Cover to Base Housing (Yellow Tape)
 EH042: 8-32 x 3/8” 18-8 S.S Button Socket Cap Screw (x4), EH062: 3/32” Allen
Key (x1)
EH085: Heater Head to Pole Neck (Green Tape)
 EH041: #10 – 24 S.S Button Socket Cap Screw (x4), EH080: #10 S.S Internal
Lock Washer (x4), EH063: 1/8” Allen Key (x1)
EH086: Pole Flange to Bottom Base (Black Tape)
 EH057: 3/8” – 16 S.S Nylon Insert Lock Nut (x4), EH056: 3/8” S.S Flat Washer
0.875” OD (x4)
EH087: Pole Neck to Pole (Orange Tape)
 EH070: 5/16” – 18 X ½” 18 – 8 S.S Button Socket Cap Screw (x4), EH081: 5/16”
S.S Internal Lock Washer (x4) EH072: 5/16” – 18 Brass Nylon Insert Lock Nut
(x4), EH088: 5/16” Allen Key (x1)
MODEL GA301-M:
EH001: Top Reflector to Support Arms (Blue Tape)
 EH027: 1/4”-20 x 1/2” S.S Carriage Bolt (x4), CH143: 1/4” S.S Flat Washer (x4),
EH028 1/4”-20 S.S Acorn Nut (x4)
EH021: Pole Package
MODEL GA301-U, GA301-T:
EH001: Top Reflector to Support Arms (Blue Tape)
 EH027: 1/4”-20 x 1/2” S.S Carriage Bolt (x4), CH143: 1/4” S.S Flat Washer (x4),
EH028 1/4”-20 S.S Acorn Nut (x4)
EH021: Pole Package
MODEL GA301-H
EH001: Top Reflector to Support Arms (Blue Tape)
 EH027: 1/4”-20 x 1/2” S.S Carriage Bolt (x4), CH143: 1/4” S.S Flat Washer (x4),
EH028 1/4”-20 S.S Acorn Nut (x4)
EH022: Hanging Package
