10.2 System Test Button
Pressing the System Test pushbutton will initiate a 30 second test of the system.
This test will comply with the UL924 self-testing and self-diagnostics by analyzing
battery voltages and output loads. All switched loads are energized during a system
test.
10.3 Alarm Silence Button
Pressing the Alarm Silence button will silence the audible alarm and also turn off
the Alarm On/Off LED. The Alarm Silence is equipped with a “ring-back” feature so
that if an alarm is still present 24 hours after the alarm is silenced, the audible alarm
will re-activate.
During a System Test and during a power outage when the system is on Inverter
Power, the audible alarm will beep momentarily once every second.
10.4 Keypad and Display Features
Using the Keypad and 4x20 Display, the user can access all features of the system
including Meter Measurements, User Settings, Test Logs, Alarm Logs, Event Logs,
System Info, Alarms and System Info. The Home Menu is a scrolling menu that
scrolls between the Company and Product information on one page and then the
Date and Time and Alarms (if Present) on another page. To Leave the Home Menu,
Press the Enter (center) Button. From there press the down arrow to scroll down to
see the available menus.
10.5 SD Card
The SD card slot is available for downloading all the Test, Event and Alarm Logs as
a backup to a computer for analysis or record keeping. To initiate the SD card
storage feature, the user must do so through the User Menu so it is password
protected. Please see the Backup Logs in the User Menu 10.13 for instructions for
this process.
10.6 USB Slot
The USB slot is not available to the User and is available only to Factory or
Qualified Field Service Technicians. Its purpose is for system updates such as
software and critical system parameter changes through a file structure and internal
flash memory drives.
10.7 Main Menu
The Main Menu is the First Menu available after the Home Page that
Automatically Scrolls between Company info and Date and Time. The Main Menu
consists of sub-menu selections and are Meter Menu, Alarms, Event Log, Test Log,
Alarm Log, User Setup, Factory Setup and System Info. To reach the Main Menu,
simply press the Enter button from the Home Page. Then use the up and down
arrow key to select between all the Sub-Menus previously listed and once the
desired Sub-Menu is reached, simply press the Enter Key to access that Sub-Menu
for immediate entry.
38 | INSTALLATION / OPERATION MANUAL
