Load Reduction Alarm
Load Reduction is an alarm available to quantify if Load Changes have occurred.
When the Load Reduction option is enabled, the actual output current is
compared to a user adjusted load current setting during an event only! It only
looks at load current during an event because with modern lighting management,
the loads can continuously change from Motion Sensors, Occupancy Sensors, etc.
These constant load changes may trigger an alarm but, the system is operating as
designed. When the Actual Output Current deviates more than 10 percent high or
10 percent low from that Load Current Setting, an alarm will be tripped. The
factory default for this setting is off and if enabled the adjustment for the load
current setting is from zero amps to system full scale current in 0.1A increments.
Relay 1
A user programmable alarm function or status function can be tied to a Form-C
relay to integrate into a building management system. The relay can be triggered
on the following status or alarm features – AC Present, Battery Charging, Inverter
On, High Temperature, Utility Failure, Near Low Battery, Low Battery, High VAC,
Low VAC and Relay Off. The factory default setting for Relay1 is off.
Relay 2
Identical to Relay 1 in function. Relay 2 is an independent relay with its own
Form-C contacts.
Backup Logs
To use the Backup Logs function, an SD card must be inserted into the SD card
slot. When the Backup Logs function is selected, ALL internal logs from Test Logs,
Event Logs, Alarm Logs and Discharge Logs will be written to the SD card. The files
that are stored are Text files for each individual log and may consist of thousands
of files. This process may take several minutes to finish due to the limitations of
the internal processor speed and all of the tasks that it is simultaneously
performing.
Contact Name
A Contact Name can be entered into the system for storage. The contact name
is then viewable in System Info. The Name can be changed using the keypad by
scrolling through the alpha/numeric selections with the up and down arrow keys.
When the correct number or letter is reached, scroll left or right for the next
character or press Enter when finished.
Contact Phone
A Contact Phone Number can be entered into the system for storage. The
contact phone number can be viewed in the System Info. The Contact Phone
number can be changed using the keypad by scrolling through the alpha/numeric
selections with the up and down arrow keys. When the correct number or letter is
reached, scroll left or right for the next character or press Enter when finished.
42 | INSTALLATION / OPERATION MANUAL
