Pre-Installation
PLANNING INSTALLATION
Ensure all parts listed in the Package Contents section are included and that you have the listed Tools and Materials Required on hand.
TOOLS REQUIRED
Pencil Drill with
3/32“ Drill bit for screws
1/4“ Drill bitt for rearhole
Measuring Tape
Phillips
screwdriver
PACKAGE CONTENTS
Part Description Quantity
A Left Drawer Slide 1
B Right Drawer Slide 1
C
Front fixing clips left/right for 5/8“ (16 mm)
drawer subfront thickness
2
D Optional spacers for 1/2“ (13 mm)
drawer subfront thickness
2
E Face Frame Bracket 2
H
F
F Panhead #6 x 1/2 in. (3,5 x 13 mm) 8
G Countersunk #6 x 5/8 in. (3,5 x 16 mm) 16
A
B
C
E
D
H Countersunk #6 x 3/4 in. (3,5 x 20 mm) 4
I Countersunk #6 x 1 in. (3,5 x 25 mm) 4
I
G
To Next Page
