Everbilt 9236061 - Drawer Installation and Removal; Installing Drawer Catches; Installing the Drawer; Removing the Drawer

9 HOMEDEPOT.COM
Please contact 1-800-305-1726 for further assistance.
Drawer Installation and Removal
1
Installing the drawer catches
2
Installing the drawer
Insert the drawer onto the glides inside the cabinet and push inside until the drawer catches click.
Face FrameFrameless
3
Removing the drawer
Gently pull each drawer catch lever
and slide the drawer out to remove.
≤ 30°
C
C
DRAWER CATCH DIMENSIONS
10 mm
3/8"
80 mm
(3-9/16")
48 mm
(1-7/8")
26 mm
(1-1/32")
Bottom
H
I
Install each drawer catch (C) into the two front corners of the drawer using #6 x 3/4 in. screws (H) or #6 x 1 in. screws (I). If you need to
install the screws at an angle, do not angle the screws more than 30°. If your door subfront is 1/2 in. (13 mm) use the optional spaces (D).
