EASY DECISION
APPLIANCE DETAILS
ELECTRICAL DETAILS UFCW661:
Rated Voltage: 220-240V / 380-415V ~3N, 50 Hz
Max Rated Inputs: 9000W (3000W for oven, 6000W for cooktop).
This information can be found on the rating plate (data label) affixed to the rear of the appliance.
HOTPLATE RATING
165mm hilight x 2 (RF, LR) 1200W each
200mm hilight x 2 (RR, LF) 1800W each
OVEN RATING
Top element 950W
Bottom element 1100W
Grilling element 2000W
Rear turbo element 2000W
Fan motor 33W
Lamp 25W
SIZES:
The appliance is supplied with one wire shelf and one oven tray. Each shelf and tray comes with a built-in
safety feature to help minimise them being accidentally pulled fully out. This comes in the way as a
“step”, positioned at the rear of the shelf or tray.
To fit them into the oven, push the shelf or tray part way into the oven at an angle, then fully insert. To
remove, repeat the process in reverse.
Relevant Sizes: DEPTH (mm) WIDTH (mm) HEIGHT (mm)
External Oven size 600 600 900 (885-915)
4
