6. View Angle Adjustment
The camera can be rotated 360°
horizontally, 140° vertically and 60°
3’rd axis view angles (as shown in Figure 8). Adjust the proper camera
view angle as needed. If a vari-focal lens is used, you may adjust the
focus and zoom of the lens to bring the object in focus. Be sure to
loosen the locking screws on the lens before you do the adjustments.
Figure 8
Lens fixing Screws
8
