ecifications
Model: EHD525EX
Pickup device: SONY 1/3” interline transfer color EXView CCD
Picture element: NTSC: 768(H) × 494(V)
PAL: 752(H) × 582(V)
Horizontal Resolution: 520 TV Lines
Sensitivity: 0.1 lux / F=1.2
S/N ratio: >52dB(AGC off)
Vari-Focal Lens: 3.6-9mm / 9-22mm IR Lens
IR Cut Removable: Yes (Auto IR Cut Removable and B/W Sensitivity
Enhanced)
Weatherproof Ratings: IP66
Electronic shutter: Up to 1/100,000
IRIS Control: Auto
Auto white balance: YES
Auto gain control: ON/OFF switch
Back light comp.: ON/OFF switch
Line Lock: ON/OFF switch for 24V AC
Flickerless: ON/OFF switch
Gamma correction: 0.45
Video output: 1.0Vp-p, 75ohm
Power source: 12V DC+/-10%, 24V AC+/-10%
Power Consumption: 5W Max. (15W when heater active;
thermostatically controlled)
Sync. mode: Internal Sync. /Line lock (Only for AC24V)
Dimension: 5.1” (W) x 3.9” (H) x 5.1” (D).
Heater auto activated
temperature:
50 degree Fahrenheit
Operating temperature: -40 ~ 122 degrees Fahrenheit, 20~80%
Weight: 3.7 lbs
3
