10
Dip Switch Functions
Vari-Focal Lens
LL (Line-Lock) OFF/ON
Set the line-lock off the camera will synchronize to the internal time base.
Set the line-lock on, the camera’s vertical synchronization can be driven by
the AC signal in the power lines.
Note: Line-Lock sync mode operation is possible only when used with
an AC power source; it’s not possible with a DC power source.
The default setting is ON.
AGC (Automatic Gain Control) OFF/ON
AGC ON: Signal strength sensitivity automatically adjusts to the high or
low light conditions. The default setting is ON.
AGC OFF: This setting should be turned switched to in an environment
with a constant light source.
