4. Re-assemble Camera
I. When mounting COLOR RUGGED DOME CAMERA on the
wall, please aim the “Wall” in line with the triangle “S” marked
on the lead frame. (Factory default)
II. When mounting COLOR RUGGED DOME CAMERA on the
ceiling, please aim the “Ceiling” in line with the triangle “S”
marked on the lead frame.
“Wall”
Figure 6-1
6
“Ceiling”
Figure 6-2
6
