68
Cleaning And Assembly Of The Oven Door
Figure 55 Figure 56
Figure 55.1
Figure 55.2 Figure 56.1 Figure 56.2
Open the door
completely by pull-
ing the oven door
toward you. Then
unlock the hinge
lock by pulling it
upwards with a
screwdriver. (See
Fig. 55.1)
Set the hinge lock
to the widest an-
gle. (See Fig. 55.2)
Bring both hinges
that connect the
oven door to the
oven to the same
position.
Then close the
oven door until it
rests against the
hinge lock. (See
Fig. 56.1)
To remove the
oven door, hold
the door with both
hands when it is at
a close level to the
closed position,
and pull it up. (See
Fig. 56.2)
To replace the oven door again reverse the procedure for removing the door.
