58
SETTING 04 INPUT/OUTPUT
The display of the settings is restricted to the Service.
► Press MENU , with the UP and DOWN buttons select
07 SETTING, press ENTER
with the UP and DOWN buttons select 04
INPUT/OUTPUT, press ENTER
► Scroll the manu with the UP and DOWN buttons:
Room -6°C
Evaporator -15°C
► Room and evaporator temperature,
Condensor 21°C
UR 44%
► Humidity and condensor temperature.
C D FE R L UR E
1 0 0 1 1 0 0
► Output staus:
C Compressor,
D Defrost
FE Evaporator Fan
R Resistence
L Internal light
UR Relative humidity
E Extractor
S4 S5
1 0
► Digital input status:
S4 microdoor
S5 pressostato
► Input status:
(1 = activated rele 0 = deactivated rele).
