40
Using Your Evinrude E-TEC Outboard
Trim Angle Adjustment
Use the trim/tilt switch to adjust the outboard
position in the tilt range or trim range.
Run the boat in the water to determine the
best trim angle.
IMPORTANT: Weight distribution can affect
the performance of the boat. Distribute weight
evenly in the boat.
The boat should accelerate quickly, plane
easily, and run parallel to the surface of the
water at high speeds.
If trim position is too LOW the front of boat will
be DOWN and push water.
If trim position is too HIGH the front of boat will
be UP and bounce.
Tilt
The tilt range allows the operator to tilt the
outboard for clearance when beaching, moor-
ing, launching, or trailering.
Trim
In most operating conditions, it is recom-
mended to trim the outboard to the full down
position when accelerating. Once on plane,
trim the outboard up for best performance.
Over-trimming increases engine RPM while
decreasing speed. The best trim setting is
when the highest speed is achieved with the
lowest engine RPM.
Shallow Water Drive
Adjust the outboard position within the tilt
range for shallow water operation.
When operating a tilted out-
board, do not run above idle speed. Keep
the water intakes submerged at all times
to prevent the engine from overheating.
1. Tilt range
2. Trim range
007028
1. Water intakes
007069
