Page #72 background imageLoading...
Page #72 background image
70
Product Information
SPECIFICATIONS
15 HO, 25, 30 Models
Displacement 35.1 cu. in. (576 cc)
Engine Type In-line, 2 Cylinder, Two-Cycle, E-TEC
Full Throttle Operating
Range
15 HP (HO) – 5500 to 6100 RPM
25, 30 HP – 5500 to 6000 RPM
Power
(1)
15 HP (HO) – 15 HP (11.2 kw) @ 5800 RPM
25 HP – 25 HP (18.4 kw) @ 5750 RPM
30 HP – 30 HP (22.1 kw) @ 5750 RPM
Idle RPM in Neutral
(2)
750 ± 50
Ignition Timing
(2)
Not Adjustable
Emission Control
System: per SAE
J1930
(2)
ECM, E-TEC (Engine Control Module, E-TEC)
Fuel Requirements
(2)
87 Pump Posted AKI (90 RON)
– Refer to Fuel Requirements on page 21
Oil – Lubricant
– Capacity
TC-W3 NMMA-certified oil or Evinrude/Johnson XD100 oil
– Refer to Oil Requirements on page 19
1.5 qt. (1.4 l)
Warning Signals Controlled by the outboard’s EMM
Battery, Minimum
(3)
640 CCA (800 MCA) 12 volt or
800 CCA (1000 MCA) 12 volt below 32°F (0°C)
Spark Plug
(2)
Refer to ECI Label
Fuses P/N 967545 – Refer to Fuse on page 55
Fuel Filter In-line Replaceable
Battery Charging 15-Amp, Fully Regulated
Gearcase – Lubricant
(4)
– Capacity
Evinrude HPF XR
11 fl. oz. (325 ml)
Power Trim/Tilt – Fluid
Capacity
11.7 fl. oz. (345 ml)
Propeller Refer to Propeller Selection on page 68
Weight
DR / DRL Models 150 /154 lbs. (68 / 70 Kg),
DEL / DTE / DTEL Models 160 / 162 /166 lbs. (73 / 74 / 75 Kg),
DPL / DHPL / HPSL Models 181 lbs. (82 Kg),
DTL / DHTL / HTSL / HPSX Models 187 lbs. (85 Kg),
HTSX Models 193 lbs. (88 Kg)
Sound at Drivers Ear
(LpA) ICOMIA 39.94
76.8 dB(A)
Transom Height DR / DTE Models – 14.5 to 15 in (368 to 381 mm)
DRL / DTEL / DPL / DTL / DHTL / DHPL / HTSL / HPSL Models – 19.5
to 20 in (495 to 508 mm)
HTSX / HPSX Models – 24.5 to 25 in (622 to 635 mm)
(1) Rated following the standards of ICOMIA 28.83, ISO 3046 and NMMA.
(2) Emission Control Information.
(3) Use a 800 CCA (1000 MCA) battery when operating in temperatures below 32°F (0°C).
(4) Use Evinrude/Johnson HPF Pro Gearcase Lubricant for high performance outboards and commercial
applications. Evinrude/Johnson HPF Pro Gearcase Lubricant delivers exceptional durability and
reliability and promotes long gearcase life in marine use.
